Pass Boxes

General Specification for Dynamic Pass Box

  • Final Supply Filter: Minipleat HEPA Filter with Hot Melt Technology, 99.99% down to 0.3 microns.
  • Lights: CFL Light through clear acrylic to get maximum illumination / UV Light.
  • Doors: Sandwitched door with double sided View Panel, Auto Lock Assembly.
  • Blower Motor: Dynamically balanced with Stator, Rotor Assembly.
  • Material of Construction : SS 304 / SS 316.
  • Type : Wall / Floor Mounted.
  • Pre Filter of EU 6 Grade, 95% down tp 5 Microns.
  • Grills: SS 304 Perforated.
  • Pressure Monitoring: Analog / Digital.
  • Air Cleanliness: ISO 5.
  • Air Velocity: 0.45 +/- 0.1 m/sec.
  • Noise Level: Less than 70 dB.

General Specification for Static Pass Box

  • Lights: CFL Light through clear acrylic to get maximum illumination / UV Light.
  • Doors: Sandwitched door with double sided View Panel, Auto Lock Assembly.
  • Material of Construction : SS 304 / SS 316.
  • Type : Wall / Floor Mounted.
